Special treatment of our gear achieve the NOISE ≤ 80DB.
Thicker body, Small volume, compact structure, higher hardness forged blade, ensure the high quality and steady performance, longer service life.
Higher cutting range, can cut different models of steel bar without moving the blades.
Pure cooper wire motor in different voltage all over the world
|
Type |
GQ-40A |
GQ-40B |
GQ-45A |
GQ-45B |
GQ-50A |
GQ-50B |
|
Power |
2.2KW |
3KW |
3KW |
3KW |
4KW |
4KW |
|
Voltage |
380V, 50HZ，3 Phase or Customized |
|||||
|
Motor speed |
2880r/min |
2880r/min |
2880r/min |
2880r/min |
2880r/min |
2880r/min |
|
Round bar |
6-30mm |
6-32mm |
6-34mm |
6-40mm |
6-40mm |
6-42mm |
|
Rebar |
6-26mm |
6-28mm |
6-32mm |
6-32mm |
6-36mm |
6-40mm |
|
Cutting freqency |
32times/min |
32times/min |
32times/min |
32times/min |
28times/min |
28times/min |
|
Weight |
280kg |
320kg |
350kg |
360kg |
510kg |
520kg |
|
Dimension |
1430*450*750mm |
1430*450*750mm |
1430*450*750mm |
1430*450*750mm |
1450*600*1010mm |
1470*580*1010mm |
Cutting Diameter: Rebar 4-12MM / Round bar 4-14MM
Cutting Length: 0.3-99m
Cutting Error: ±5mm
Weight: 400kg
Capacity: 4-10mm (Single line) / 4-8mm (Double line)
Power: Feeding - 9KW / Bending - 3.75KW
Max.Feeding Speed：85M/MIN
Dimension: 3630*1100*1900MM
Bending Diameter: Rebar 6-32MM / Round bar 6-36mm
Motor Power: 3KW-4P
Motor Speed:1440R/MIN
Weight: 310KG
Cutting Diameter: Rebar 6-28mm / Round bar 6-32mm
Motor Power: 3KW-3P
Cutting Speed: 32T/MIN
Weight: 320KG
Bending Diameter: Rebar 6-28MM / Round bar 6-30MM
Motor Power: 3KW-4P
Motor Speed: 1440r/min
Weight: 260KG
If you have any inquires about the construction machinery & road machinery, please donnot hesitate to contact us. We will reply you ASAP.
